public adress system full set Audio Matrix Controller for Public Address System

Brand Name : FTD

Model Number : FTD-16MX

Place of Origin : CHINA

MOQ : 2pieces

Price : USD433.5~435.5

Supply Ability : 1000cottons

Delivery Time : 5-8work days

Packaging Details : 484(W)*390(D)*133(H)mm

Description : Intelligent 16 Channel Audio Matrix Controller

Frequency Response : 60-16KHz (±3dB)

DNR sensitivity : MW 5Mv/m

power supply : AC 230V or 110V, 50-60Hz

Dimension : 484(W)*390(D)*133(H)mm

Gross Weight : 8.5kg

warranty : 5years

Channel : 16 channel inputs and 16 channel outputs

Max Capacity : 128 zones by cascaded 8 units together

Call Station Input : Call station input 1-5, RJ45 port, 10kΩ, 10V, balanced

Display : 128×64 LCD display in English

Contact Now

Features:

Public address system classic cost-effective medium to big-scale sound system intelligent controller.
Ideal PA sound system controller for school, shopping mall, hotel, and intelligent office etc.
All in one intelligent PA sound system include 16 channel audio matrix, Mp3 player & USB, 16 zone remote paging system, fire alarm & voice evacuation system interface, weekly scheduled timer and power sequencer.
16 Channel audio matrix controller with 16 channel inputs and 16 outputs.
Zone capacity expandable to 128 zones by cascaded 8 unit together, master controller and 7 units slave controllers.
All in one intelligent PA System controller built in 16 channel audio matrix, weekly timer, 16 zone speaker selector, Mp3 player, remote 16 zone paging controller, fire alarm and voice evacuation system interface and programmable power sequencer.

Model	FTD-16MX
Description	Intelligent 16 Channel Audio Matrix Controller
Channel	16 channel inputs and 16 channel outputs
Max Capacity	128 zones by cascaded 8 units together
Call Station Input	Call station input 1-5, RJ45 port, 10kΩ, 10V, balanced
Input	Line 1-16: 10kΩ, 330mV, unbalanced RCA input.EMC1: 10kΩ, 330mV, unbalanced
Output	Line 1-16: 10kΩ, 330mV, unbalanced RCA output ,EMC1: 10kΩ, 0.775mV, 0dB, unbalanced
Alarm	Alarm input: 0V, closed circuit contact Alarm output, 0V, closed circuit contact
Display	128×64 LCD display in English
Frequency Response	60-16KHz (±3dB)
Control	16 zone output volume controls Menu buttons: up, enter & down ID dip switch Master or slave dip switch
Protection	AC fuse 0.5A, 1PCS
Power Consumption	20W
Power Supply	AC 230V or 110V, 50-60Hz
Dimension	484(W)×390(D)×133(H)mm
Net Weight	7.1kg
Packaging	520(W)×455(D)×185(H)mm
Gross Weight	8.5kg

public adress system full set Audio Matrix Controller for Public Address System

exihibition

FAQ:

1. Are you manufacturer?
Yes, we are public address system manufacturer located in Guangzhou, China.
Welcome to visit our factory.

2. Is sample order available? Is free sample available?
Firstly, sample order is available. Secondly, for new clients, we will return the sample fee after big order placed.

3. What's your warranty period?
Our warranty period is 12 months for speaker.

4. What's your payment terms?
We accept Western Union and TT. 30% deposit in advance, balance 70% before shipment.

5. Where is your main market?
Customers are mainly from Europe, Middle East and South Asia.

6. How many days do you need to prepare for the goods?
It takes 30 working days for large order.
