Class D Public Address System Single Channel 500W Power Amplifier 1U Hight

Product Categories
Guangzhou FTD Audio Electronics Limited
Contact Now

Class D Public Address System Single Channel 500W Power Amplifier 1U Hight

  • 1
  • 2
  • 3

Brand Name : FTD

Model Number : FA-500D

Certification : CE

Place of Origin : Guangzhou China

MOQ : 10 pcs

Price : $ 156~158

Payment Terms : T/T

Supply Ability : 1000 Piece/Pieces per Month

Delivery Time : 7 work days

Packaging Details : carton

Material : UV protected ABS enclosure in green

Communication : AUX, Audio Line

Frequency Range : 20Hz-20KHz

Type : Active

Special Feature : Wireless

Weight : 5.5kg

Contact Now

Class-D Single Channel 500W Power Amplifier Black 1 U Hight

Description:

The FA-500 range digital class-D power amplifier is of switching power technology, which features of minimum power consumption and
much higher efficiency up to 85%, moreover it helps to save installation rack space, generate less heat so as to extend its
performance life span as a result.

The FA-500D is of rated power output at 500W, so it could be used as digital public address system at minimum cost. The versatile
loudspeaker outputs of both
high impedance 100V & low impedance 4-16ohms enable it meet both PA fixed installation and Hi-fi stereo sound installation jobs.

There are one balanced inputs by phoenix connector with gain control. Speaker outputs both by 100V & 4-16ohms. The built-in
high-pass filters could be enabled or disabled through the dip switch pre-setting.
Automatic standby enable after no detection of signal input for one minute, immediately wake up at sight of any input. Visual
working status indicators include protection, clip, input and output for easy supervision. With complete short circuit, overload,
high temp, clip and DC protection.

Switchable AC power supply from 115V to 230V, thus it support worldwide sound system installation. DC24V operation is optional at
order request for immediately shipment as well.

Specification:

Model FA-120D FA-240D FA-350D FA-500D
Description Class-D Single Channel Power Amplifier
Rated Power Output 120W 240W 350W 500W
Speaker Output 4-16Ω & 100V
Frequency Response L/H Cut OFF 20Hz-20KHz (+1/-2dB)
L/H Cut ON 70Hz-10KHz (+1/-3dB)
Input 0.775V, 0dBu, balanced phoenix connector
Input Impedance 10KΩ
THD <0.1% (1KHz/-3dBv, 100W)
S/N Ratio >80dB
Crosstalk >60dB, 1KHz, Max output
Power Consumption 200W 300W 420W 550W
Power Supply AC input switchable between 115V & 230V, 50-60Hz
24V DC input as option at order request.
Dimension 482(W)x420(D)x44(H) mm
Weight 4.2kg 4.5kg 5KG 5.5KG

Features:

Switching power technology digital power amplifier
Class-D PA power amplifier of minimum power consumption
Less rack space and less heat generation
Single channel power amplifier into 19” rack mount unit
Rated power output at 350W
Speaker outputs 4-16Ω/100V
Balanced XLR input by phoenix connector
Each input with separate gain control.
Each channel with high-cut filter.
Built-in auto standby feature to save power consumption
Separate indicators for protection, clip, input and output
Complete short circuit, overload, high temp, clip and DC protection
Wide AC input switchable between 115V and 230V
24V DC input as option at order request.
